Product Introduction
KE-T100 Telescopic sliding door - Shanghai Keer design and installation maintenance
Telescopic sliding doors are linear models with more than one door leaf per side. The inner door is connected to the outer via deflection rollers, and slides at twice the speed. This enables rapid opening in very wide passages. The Keer telescopic door is especially suitable where passagways are narrow but the widest possible passage is required to accommodate pedestrian traffic.
FUNCTION INTRODUCTION
1. Two kinds of high-strength aluminum alloy guide rails is a comblination of special accessories, which is easy to instal, and the appearance is strong and beautiful.
2. High-quality EPDM strips are inserted in the middle of guide rail channel, it can absorb the vipation and noise during operation, the automatic doors are running more quietly.
3. Overlapping leaves are linked by belts and belt pulleys; its operation is stable and reliable.
4. Built-in chip has the ability of intelligent adjustments that realize automatic control process, The door leaves can maintain optimal operation status without weight adjustment because the controller has the adaptability of adjusting load automatically.
5. Two-way automatic reverse function ensures its safety performance is more outanding.
6. Faster opening speed and more humanized design
TECHNICAL DATA
Door configuration： Two-leaf, Four-leaf
Door leaf weight： ≤2×150kg / ≤ 4×100kg
Clean open width： 1200-2700mm,2200-3900mm
Power voltage： AC 220V±10%,50/60Hz AC 110V±10%,50-60Hz
Power consumption： <100W
Opening speed： 300-550mm/S(adjustable)
Closing speed： 200-550mm/S(adjustable)
Hold-open time： 1-10S(adjustable)
Closed force F： >100N
Manual push： <100N
Working environment temperature： -20℃~ +50℃
